Tilak Tubefittings is a reputable manufacturer and supplier of top-notch Brass Hydraulic Fittings, located in Chennai, India. With a keen emphasis on precision engineering and unwavering quality, the company provides fittings that meet the rigorous demands of hydraulic systems across various industries. Crafted from premium-grade brass and utilizing advanced machining techniques, these fittings guarantee excellent sealing, precise dimensions, and a long lifespan. Tilak Tubefittings adheres to stringent quality control measures to ensure their products are reliable and perform efficiently under pressure. Their Brass Hydraulic Fittings are celebrated for their corrosion resistance, durability, and straightforward installation, making them a go-to choice for both domestic and international clients.
Brass hydraulic fittings are mainly composed of copper (approximately 60-70%) and zinc (30-40%), with small amounts of copper and other materials to enhance mechanical properties These fittings exhibit good mechanical properties, with good tensile strength ( up to 350 MPa) along with corrosion resistance, enabling a variety of hydraulic applications Suitable brass fittings have the advantage of being lightweight, easy to install, and resistant to rust and corrosion, ensuring longevity and reliability Besides which, provide excellent thermal and electrical conductivity, so that their oil and gas, automotive and automobile manufacturing -are ideal for use in hydraulic systems in such applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | BRASS |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM) L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY) S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | NATURAL FINISH, NICKEL PLATED |
| TEMPERATURE | BRASS – (-60*C TO 175*C) |
| MATERIAL DESIGNATOR | BRASS – ASTM B16 UNS C36000 , ASTM B282 ALLOY 37700 , JIS H3250 C3604 , C3771 , JIS H3250 C3771. |
UNS No. | AS No. | Common Name | BSI No. | ISO No. | JIS No. | Copper % | Zinc % | Lead % | Other |
C21000 | 210 | 95/5 Gilding metal | – | CuZn5 | C2100 | 94-96 | ~5 | | – |
C22000 | 220 | 90/10 Gilding metal | CZ101 | CuZn10 | C2200 | 89-91 | ~10 | | – |
C23000 | 230 | 85/15 Gilding metal | Cz103 | CuZn20 | C2300 | 84-86 | ~15 | | – |
C24000 | 240 | 80/20 Gilding metal | Cz103 | CuZn20 | C2400 | 78.5-81.5 | ~20 | | – |
C26130 | 259 | 70/30 Arsenical brass | Cz126 | CuZn30As | C4430 | 69-71 | ~30 | | Arsenic 0.02-0.06 |
C26000 | 260 | 70/30 Brass | Cz106 | CuZn30 | C2600 | 68.5-71.5 | ~30 | | – |
C26800 | 268 | Yellow brass (65/35) | Cz107 | CuZn33 | C2680 | 64-68.5 | ~33 | | – |
C27000 | 270 | 65/35 Wire brass | Cz107 | CuZn35 | – | 63-68.5 | ~35 | | – |
C27200 | 272 | 63/37 Common brass | Cz108 | CuZn37 | C2720 | 62-65 | ~37 | | – |
C35600 | 356 | Engraving brass, 2% lead | – | CuZn39Pb2 | C3560 | 59-64.5 | ~39 | 2.0-3.0 | – |
C37000 | 370 | Engraving brass, 1% lead | – | CuZn39Pb1 | C3710 | 59-62 | ~39 | 0.9-1.4 | – |
C38000 | 380 | Section brass | Cz121 | CuZn43Pb3 | – | 55-60 | ~43 | 1.5-3.0 | Aluminum 0.1-0.6 |
C38500 | 385 | Free cutting brass | Cz121 | CuZn39Pb3 | – | 56-60 | ~39 | 2.5-4.5 | – |
Brass Hydraulic Fittings are generally made from high-quality brass alloys, primarily consisting of copper and zinc, with carefully controlled amounts of lead or other elements to enhance machinability. This specific composition provides outstanding corrosion resistance, particularly against water, oils, and mild chemicals. On the mechanical side, brass fittings boast good tensile strength, ductility, and impact resistance, enabling them to handle moderate to high hydraulic pressures. They also feature low friction, impressive wear resistance, and stable performance across a wide temperature range, ensuring reliable sealing and a long operational life in hydraulic systems.
Contact us to get a quick quote for your requirement.
Brass Hydraulic Fittings find extensive use in hydraulic and fluid transfer systems where reliability and corrosion resistance are crucial. They are commonly utilized in industrial machinery, hydraulic pumps, compressors, construction equipment, and agricultural machinery. These fittings are also ideal for pneumatic systems, lubrication lines, and low to medium pressure hydraulic circuits. Thanks to their rust resistance and ease of installation, they are favored in various applications, ensuring that systems run smoothly and efficiently. Whether in a factory or on a farm, these fittings play a vital role in maintaining the integrity of hydraulic systems.
Please feel free to contact us if you need any further information or for enquiry.
