Tilak Tubefittings is a well-respected manufacturer and supplier of top-notch Pressure Gauge Connectors located in Chennai, India. They cater to a variety of industrial sectors, both locally and internationally. These connectors are expertly designed to create secure, leak-free connections between pressure gauges and pipelines, ensuring precise pressure readings even in tough conditions. Crafted from high-quality raw materials and utilizing advanced machining techniques, Tilak Tubefittings adheres to strict quality standards. Renowned for their dimensional accuracy, durability, and impressive pressure resistance, these connectors are ideal for hydraulic, pneumatic, and process control systems, delivering reliability and consistent performance in critical applications.
A manometer connector, usually made of stainless steel or brass, is manufactured to connect manometers in systems for accurate measurements In addition to alloys such as SS 316 to ensure corrosion resistance. Mechanically, it offers high tensile strength (between 500-700 MPa), good strength and thermal resistance. These connections can withstand pressures of 6000 psi or more depending on the design. Benefits include ease of installation, leak-proof seals, corrosion resistance and compatibility with pressure gauges for reliable operation in harsh environments
| STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS, COPPER, DUPLEX, SUPER DUPLEX, INCONEL, MONEL, HASTELLOY, 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20 |
| SERIES | LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| BODY TYPE | BAR STOCK |
| SURFACE | CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE, |
| STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
Pressure Gauge Connectors are typically made from materials like stainless steel, carbon steel, brass, or alloy steel, chosen based on the specific needs of the application. This careful selection ensures they have excellent resistance to corrosion, pressure, and temperature fluctuations. On the mechanical side, these connectors boast high tensile strength, good yield strength, and impressive hardness to handle vibrations and cyclic loads. With precision threading for a tight seal and outstanding impact and fatigue resistance, they offer reliable performance. Their sturdy construction allows them to perform steadily under high pressure, making them perfect for demanding industrial operations.
| CONNECTORS FOR PRESSURE GAUGE DN63 | ||||
|---|---|---|---|---|
| Thread type | Brass | Max pressure | AISI316 | Max pressure |
| G1/8B | 684 | 630 bar | 692 | 1000 bar |
| G1/4B G1/4B DIN | 675 5635 | 800 bar 800 bar | 688 3828 | 1250 bar 1250 bar |
| G3/8B G3/8B w/spigot | 680 6379 | 1000 bar 1000 bar | 141 | 1600 bar |
| G1/2B | 690 | 1250 bar | 693 | 1600 bar |
| 1/4 BSP T | 3399 | 1250 bar | ||
| 1/4 flare (7/16-UNF20(SAE)) 3/8 flare (5/8-18 UNF(SAE)) | 687 6931 | 800 bar 1000 bar | 3219 | 1250 bar |
| 1/8 NPT 1/4 NPT 1/2 NPT | 4047 681 | 630 bar 800 bar | 5158 4050 4051 | 1000 bar 1250 bar 1600 bar |
| Throttle screw – Standard damping – Powerfull damping | . 152 2129 | . 1427 | ||
| M10x0,75 | 1804 | |||
| M12x1,5 (for Ø6mm tube, compr. gland) | 3872 | |||
| Carbon steel | ||||
| Union – M12x1,5 Olive – Ø6 mm | 1387 1388 | |||
| Gaket – PTFE | . 0405-004 | |||
| Extra gasket G1/4 G3/8 G1/2 | Fiber H143 H144 H145 | Copper 8760 . 8637 |
Contact us to get a quick quote for your requirement.
Tilak Tube Fittings is a leading supplier and stockist of premium Pressure Gauge Connector in Chennai, India. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
Pressure Gauge Connectors play a crucial role in linking pressure gauges to pipelines, valves, or equipment for accurate pressure monitoring. They are vital components in hydraulic and pneumatic systems, oil and gas operations, chemical and petrochemical facilities, power generation plants, and water treatment systems. Additionally, these connectors find their place in instrumentation panels, compressors, and various other applications where precise pressure measurement is essential. Their versatility and reliability make them indispensable in a wide range of industrial settings, ensuring that operations run smoothly and efficiently.
Please feel free to contact us if you need any further information or for enquiry.
